Android TabLayout Example

activity_main.xml

<?xml version="1.0" encoding="utf-8"?>
<android.support.design.widget.CoordinatorLayout
    android:id="@+id/coordinator_layout"
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context=".MainActivity"
    >
    <android.support.design.widget.AppBarLayout
        android:id="@+id/app_bar_layout"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        app:theme="@style/ThemeOverlay.AppCompat.Dark.ActionBar"
        >
        <android.support.v7.widget.Toolbar
            android:id="@+id/toolbar"
            android:layout_width="match_parent"
            android:layout_height="?attr/actionBarSize"
            app:popupTheme="@style/ThemeOverlay.AppCompat.Light"
            app:layout_scrollFlags="scroll|enterAlways"
            />
        <android.support.design.widget.TabLayout
            android:id="@+id/tab_layout"
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            >
        </android.support.design.widget.TabLayout>
    </android.support.design.widget.AppBarLayout>

    <android.support.v4.view.ViewPager
        android:id="@+id/view_pager"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        app:layout_behavior="@string/appbar_scrolling_view_behavior"
        />
</android.support.design.widget.CoordinatorLayout>
MainActivity.java

package com.cfsuman.me.androidcodesnippets;

import android.app.Activity;
import android.content.Context;
import android.support.design.widget.CoordinatorLayout;
import android.support.design.widget.TabLayout;
import android.support.v4.view.PagerAdapter;
import android.support.v4.view.ViewPager;
import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.support.v7.widget.Toolbar;


public class MainActivity extends AppCompatActivity {
    private Context mContext;
    private Activity mActivity;

    private CoordinatorLayout mCLayout;
    private Toolbar mToolbar;
    private TabLayout mTabLayout;
    private ViewPager mViewPager;


    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        // Get the application context
        mContext = getApplicationContext();
        mActivity = MainActivity.this;

        // Get the widget reference from XML layout
        mCLayout = (CoordinatorLayout) findViewById(R.id.coordinator_layout);
        mToolbar = (Toolbar) findViewById(R.id.toolbar);
        mTabLayout = (TabLayout) findViewById(R.id.tab_layout);
        mViewPager = (ViewPager) findViewById(R.id.view_pager);

        // Set a title for toolbar
        mToolbar.setTitle("TabLayout Example");

        // Set the support action bar
        setSupportActionBar(mToolbar);

        //getSupportActionBar().setDisplayHomeAsUpEnabled(true);

        // Initialize a new instance of PagerAdapter
        PagerAdapter adapter = new SimpleFragmentPagerAdapter(
                getSupportFragmentManager(),
                mActivity
        );

        // Set a PagerAdapter for ViewPager
        mViewPager.setAdapter(adapter);

        // Setup the TabLayout with ViewPager
        mTabLayout.setupWithViewPager(mViewPager);
    }
}
res/layout/fragment_page_layout.xml

<FrameLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context=".PageFragment"
    android:background="#cfcdbb"
    >
    <TextView
        android:id="@+id/text_view"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:text="@string/hello_blank_fragment"
        android:gravity="center"
        android:textSize="50sp"
        />
</FrameLayout>
PageFragment.java

package com.cfsuman.me.androidcodesnippets;

import android.os.Bundle;
import android.support.v4.app.Fragment;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.TextView;

public class PageFragment extends Fragment{
    private static final String ARG_PARAM1 = "param1";
    private static final String ARG_PARAM2 = "param2";

    private String mParam1;
    private String mParam2;

    public PageFragment(){

    }

    public static PageFragment newInstance(String param1, String param2){
        PageFragment fragment = new PageFragment();
        Bundle args = new Bundle();
        args.putString(ARG_PARAM1,param1);
        args.putString(ARG_PARAM2,param2);
        fragment.setArguments(args);
        return fragment;
    }

    @Override
    public void onCreate(Bundle saveInstanceState){
        super.onCreate(saveInstanceState);
        if(getArguments() != null){
            mParam1 = getArguments().getString(ARG_PARAM1);
            mParam2 = getArguments().getString(ARG_PARAM2);
        }
    }

    @Override
    public View onCreateView(LayoutInflater inflater, ViewGroup container, Bundle saveInstanceState){
        View view = inflater.inflate(R.layout.fragment_page_layout, container, false);
        TextView tv = (TextView) view.findViewById(R.id.text_view);
        tv.setText(mParam1 + " " + mParam2);
        return view;
    }
}
SimpleFragmentPagerAdapter.java

package com.cfsuman.me.androidcodesnippets;


import android.content.Context;
import android.support.v4.app.Fragment;
import android.support.v4.app.FragmentManager;
import android.support.v4.app.FragmentPagerAdapter;


public class SimpleFragmentPagerAdapter extends FragmentPagerAdapter {
    private Context mContext;
    private String[] tabTitles = {"TAB 1","TAB 2","TAB 3","TAB 4"};

    public SimpleFragmentPagerAdapter(FragmentManager fm, Context context){
        super(fm);
        mContext = context;
    }

    @Override
    public Fragment getItem(int position){
        return PageFragment.newInstance("TAB",position+1+"");
    }

    @Override
    public int getCount(){
        return tabTitles.length;
    }

    @Override
    public CharSequence getPageTitle(int position){
        return tabTitles[position];
    }
}
