Sunday, May 29, 2016

android - ActionBar up navigation example

activity_main.xml

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:paddingBottom="@dimen/activity_vertical_margin"
    android:paddingLeft="@dimen/activity_horizontal_margin"
    android:paddingRight="@dimen/activity_horizontal_margin"
    android:paddingTop="@dimen/activity_vertical_margin"
    tools:context=".MainActivity"
    >
    <Button
        android:id="@+id/btn_next"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Go To Next"
        />
    <TextView
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Main Activity"
        android:textStyle="bold"
        android:textSize="30sp"
        android:textColor="#ff0000"
        android:layout_centerInParent="true"
        />
</RelativeLayout>
MainActivity.java

package com.cfsuman.me.androidcodesnippets;

import android.app.Activity;
import android.content.Context;
import android.content.Intent;
import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.view.View;
import android.widget.Button;

public class MainActivity extends AppCompatActivity {
    private Context mContext;
    private Activity mActivity;

    private Button mButtonNext;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        // Get the application context
        mContext = getApplicationContext();
        mActivity = MainActivity.this;

        // Get the widget reference from XML layout
        mButtonNext = (Button) findViewById(R.id.btn_next);

        // Set a click listener for next button
        mButtonNext.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {
                // Initialize an intent to navigate next activity
                Intent intent = new Intent(mContext, SecondActivity.class);
                startActivity(intent);
            }
        });
    }
}
activity_second.xml

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:paddingBottom="@dimen/activity_vertical_margin"
    android:paddingLeft="@dimen/activity_horizontal_margin"
    android:paddingRight="@dimen/activity_horizontal_margin"
    android:paddingTop="@dimen/activity_vertical_margin"
    tools:context=".SecondActivity"
    android:background="#ffaeae"
    >
    <Button
        android:id="@+id/btn_next"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Go To Next"
        />
    <TextView
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Second Activity"
        android:textStyle="bold"
        android:textSize="30sp"
        android:textColor="#309759"
        android:layout_centerInParent="true"
        />
</RelativeLayout>
SecondActivity.java

package com.cfsuman.me.androidcodesnippets;

import android.app.Activity;
import android.content.Context;
import android.content.Intent;
import android.support.v7.app.ActionBar;
import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.view.View;
import android.widget.Button;

public class SecondActivity extends AppCompatActivity {
    private Context mContext;
    private Activity mActivity;

    private Button mButtonNext;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_second);

        // Get the application context
        mContext = getApplicationContext();
        mActivity = SecondActivity.this;

        // Get a support ActionBar
        ActionBar ab = getSupportActionBar();

        // Enable the up button
        ab.setDisplayHomeAsUpEnabled(true);

        // Get the widget reference from XML layout
        mButtonNext = (Button) findViewById(R.id.btn_next);

        // Set a click listener for next button
        mButtonNext.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {
                // Initialize an intent to navigate next activity
                Intent intent = new Intent(mContext, ThirdActivity.class);
                startActivity(intent);
            }
        });
    }
}
activity_third.xml

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:paddingBottom="@dimen/activity_vertical_margin"
    android:paddingLeft="@dimen/activity_horizontal_margin"
    android:paddingRight="@dimen/activity_horizontal_margin"
    android:paddingTop="@dimen/activity_vertical_margin"
    tools:context=".ThirdActivity"
    android:background="#acdfad"
    >
    <Button
        android:id="@+id/btn_next"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Go To Next"
        />
    <TextView
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Third Activity"
        android:textStyle="bold"
        android:textSize="30sp"
        android:textColor="#2e6dda"
        android:layout_centerInParent="true"
        />
</RelativeLayout>
ThirdActivity.java

package com.cfsuman.me.androidcodesnippets;

import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;

public class ThirdActivity extends AppCompatActivity {

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_third);
    }
}
AndroidManifest.xml

<?xml version="1.0" encoding="utf-8"?>
<manifest
    xmlns:android="http://schemas.android.com/apk/res/android"
    package="com.cfsuman.me.androidcodesnippets"
    >

    <uses-permission android:name="android.permission.INTERNET" />
    <uses-permission android:name="android.permission.ACCESS_NETWORK_STATE" />

    <application
        android:allowBackup="true"
        android:icon="@mipmap/ic_launcher"
        android:label="@string/app_name"
        android:supportsRtl="true"
        android:theme="@style/AppTheme">
        <activity
            android:name=".MainActivity"
            android:label="@string/title_activity_main">
            <intent-filter>
                <action android:name="android.intent.action.MAIN" />

                <category android:name="android.intent.category.LAUNCHER" />
            </intent-filter>
        </activity>
        <activity
            android:label="@string/title_activity_second"
            android:name=".SecondActivity"
            android:parentActivityName=".MainActivity"
            >
            <!-- Parent activity meta data to support 4.0 and lower api version -->
            <meta-data
                android:name="android.support.PARENT_ACTIVITY"
                android:value=".MainActivity" />
        </activity>
        <activity
            android:label="@string/title_activity_third"
            android:name=".ThirdActivity"
            android:parentActivityName=".SecondActivity"
            >
            <meta-data
                android:name="android.support.PARENT_ACTIVITY"
                android:value=".MainActivity" />
        </activity>
    </application>

</manifest>
