Tuesday, March 29, 2016

Android horizontal RecyclerView example

activity_main.xml

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:id="@+id/rl"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:padding="16dp"
    tools:context=".MainActivity"
    android:background="#f7eaf9"
    >
    <android.support.v7.widget.RecyclerView
        android:id="@+id/recycler_view"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:background="#fd7d7d"
        >
    </android.support.v7.widget.RecyclerView>
</RelativeLayout>
res/layout/custom_view.xml

<?xml version="1.0" encoding="utf-8"?>
<android.support.v7.widget.CardView
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:card_view="http://schemas.android.com/apk/res-auto"
    android:id="@+id/card_view"
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    card_view:cardCornerRadius="4dp"
    card_view:cardElevation="4dp"
    card_view:cardMaxElevation="6dp"
    card_view:contentPadding="15dp"
    android:layout_margin="5dp"
    card_view:cardBackgroundColor="#c4dcdf"
    >
    <TextView
        android:id="@+id/tv"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:textColor="#2351cf"
        android:fontFamily="sans-serif-condensed"
        android:textStyle="bold"
        />
</android.support.v7.widget.CardView>
MainActivity.java

package com.cfsuman.me.androidcodesnippets;

import android.app.Activity;
import android.content.BroadcastReceiver;
import android.content.Context;
import android.content.Intent;
import android.content.IntentFilter;
import android.graphics.Color;
import android.support.v4.content.LocalBroadcastManager;
import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.support.v7.widget.LinearLayoutManager;
import android.support.v7.widget.RecyclerView;
import android.widget.RelativeLayout;

import java.util.ArrayList;
import java.util.List;
import java.util.Random;


public class MainActivity extends AppCompatActivity {

    private Context mContext;
    private Activity mActivity;

    private RelativeLayout mRelativeLayout;
    private RecyclerView mRecyclerView;
    private RecyclerView.LayoutManager mLayoutManager;
    private RecyclerView.Adapter mAdapter;

    private Random mRandom = new Random();

    // Initialize a new BroadcastReceiver instance
    private BroadcastReceiver mBroadcastReceiver = new BroadcastReceiver() {
        @Override
        public void onReceive(Context context, Intent intent) {
            // Receive the broadcast message
            int receivedColor = intent.getIntExtra("Color",Color.WHITE);
            mRelativeLayout.setBackgroundColor(receivedColor);
        }
    };


    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        // Get the application context
        mContext = getApplicationContext();

        // Get the activity
        mActivity = MainActivity.this;

        // Register the Local Broadcast
        LocalBroadcastManager.getInstance(mContext).registerReceiver(
                mBroadcastReceiver,
                new IntentFilter("BROADCAST_COLOR")
        );

        // Get the widgets reference from XML layout
        mRelativeLayout = (RelativeLayout) findViewById(R.id.rl);
        mRecyclerView = (RecyclerView) findViewById(R.id.recycler_view);

        // Specify a layout for RecyclerView
        // Create a horizontal RecyclerView
        mLayoutManager = new LinearLayoutManager(
                mContext,
                LinearLayoutManager.HORIZONTAL,
                false
        );
        mRecyclerView.setLayoutManager(mLayoutManager);

        // Initialize a new colors list
        List<String> colors = new ArrayList<>();

        // Put some colors on the list
        for (int i=0;i<50;i++){
            // Add a random color to the list
            colors.add(getRandomHSVColor() + "");
        }

        // Initialize a new Adapter for RecyclerView
        mAdapter = new ColorsAdapter(mContext,colors);

        // Set an adapter for RecyclerView
        mRecyclerView.setAdapter(mAdapter);

    }

    // Custom method to generate random HSV color
    public int getRandomHSVColor(){
        // Generate a random hue value between 0 to 360
        int hue = mRandom.nextInt(361);
        // We make the color depth full
        float saturation = 1.0f;
        // We make a full bright color
        float value = 1.0f;
        // We avoid color transparency
        int alpha = 255;
        // Finally, generate the color
        int color = Color.HSVToColor(alpha, new float[]{hue, saturation, value});
        // Return the color
        return color;
    }
}
ColorsAdapter.java

package com.cfsuman.me.androidcodesnippets;

import android.content.Context;
import android.content.Intent;
import android.support.v4.content.LocalBroadcastManager;
import android.support.v7.widget.CardView;
import android.support.v7.widget.RecyclerView;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.TextView;

import java.util.List;


public class ColorsAdapter extends RecyclerView.Adapter<ColorsAdapter.ViewHolder> {
    private Context mContext;
    private List<String> mDataSet;

    public ColorsAdapter(Context context, List<String> list){
        mContext = context;
        mDataSet = list;
    }

    public static class ViewHolder extends RecyclerView.ViewHolder{
        public CardView mCardView;
        public TextView mTextView;

        public ViewHolder(View v){
            super(v);
            // Get the widget reference from the custom layout
            mCardView = (CardView) v.findViewById(R.id.card_view);
            mTextView = (TextView) v.findViewById(R.id.tv);
        }
    }

    @Override
    public ColorsAdapter.ViewHolder onCreateViewHolder(ViewGroup parent, int viewType){
        View v = LayoutInflater.from(mContext).inflate(R.layout.custom_view,parent,false);
        ViewHolder vh = new ViewHolder(v);

        // Return the ViewHolder
        return vh;
    }

    @Override
    public void onBindViewHolder(ViewHolder holder, int position){
        // Get the current color from the data set
        String color = mDataSet.get(position);
        final int colorValue = Integer.parseInt(color);

        // Set the TextView widget text
        holder.mTextView.setText(color);

        // Set the CardVIew background color
        holder.mCardView.setCardBackgroundColor(colorValue);

        // Set the TextView text color same as CardView background color
        holder.mTextView.setTextColor(colorValue);

        // Set a click listener for CardView
        holder.mCardView.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {
                // Initialize a new Intent
                Intent intent = new Intent("BROADCAST_COLOR");
                intent.putExtra("Color",colorValue);

                // Broadcast the selected color value
                LocalBroadcastManager.getInstance(mContext).sendBroadcast(intent);
            }
        });
    }

    @Override
    public int getItemCount(){
        // Count the items
        return mDataSet.size();
    }
}
build.gradle [depecdencies]

    compile 'com.android.support:cardview-v7:23.2.1'
    compile 'com.android.support:recyclerview-v7:23.2.1'
