android - How to create a color picker dialog

activity_main.xml

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:id="@+id/rl"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:paddingLeft="@dimen/activity_horizontal_margin"
    android:paddingRight="@dimen/activity_horizontal_margin"
    android:paddingTop="@dimen/activity_vertical_margin"
    android:paddingBottom="@dimen/activity_vertical_margin"
    tools:context=".MainActivity"
    >
    <Button
        android:id="@+id/btn"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Show Color Picker"
        />
</RelativeLayout>
MainActivity.java

package com.cfsuman.me.colorpickerexample;

import android.app.AlertDialog;
import android.content.Context;
import android.graphics.Color;
import android.graphics.Point;
import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.view.Display;
import android.view.View;
import android.view.WindowManager;
import android.widget.AdapterView;
import android.widget.Button;
import android.widget.GridView;
import android.widget.RelativeLayout;

public class MainActivity extends AppCompatActivity {
    private Context mContext;
    private int mPickedColor = Color.WHITE;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        // Get the widgets reference from XML layout
        final RelativeLayout rl = (RelativeLayout) findViewById(R.id.rl);
        Button btn = (Button) findViewById(R.id.btn);

        // Set the application context
        mContext = getApplicationContext();

        // Set an click listener for Button widget
        btn.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {
                // Get a GridView object from ColorPicker class
                GridView gv = (GridView) ColorPicker.getColorPicker(MainActivity.this);

                // Initialize a new AlertDialog.Builder object
                AlertDialog.Builder builder = new AlertDialog.Builder(MainActivity.this);

                // Set the alert dialog content to GridView (color picker)
                builder.setView(gv);

                // Initialize a new AlertDialog object
                final AlertDialog dialog = builder.create();

                // Show the color picker window
                dialog.show();

                // Set the color picker dialog size
                dialog.getWindow().setLayout(
                        getScreenSize().x - rl.getPaddingLeft() - rl.getPaddingRight(),
                        getScreenSize().y - getStatusBarHeight() - rl.getPaddingTop() - rl.getPaddingBottom());

                // Set an item click listener for GridView widget
                gv.setOnItemClickListener(new AdapterView.OnItemClickListener() {
                    @Override
                    public void onItemClick(AdapterView<?> parent, View view, int position, long id) {
                        // Get the pickedColor from AdapterView
                        mPickedColor = (int) parent.getItemAtPosition(position);

                        // Set the layout background color as picked color
                        rl.setBackgroundColor(mPickedColor);

                        // close the color picker
                        dialog.dismiss();
                    }
                });
            }
        });
    }

    // Custom method to get the screen width in pixels
    private Point getScreenSize(){
        WindowManager wm = (WindowManager)mContext.getSystemService(Context.WINDOW_SERVICE);
        Display display = wm.getDefaultDisplay();
        Point size = new Point();
        //Display dimensions in pixels
        display.getSize(size);
        return size;
    }

    // Custom method to get status bar height in pixels
    public int getStatusBarHeight() {
        int height = 0;
        int resourceId = getResources().getIdentifier("status_bar_height", "dimen", "android");
        if (resourceId > 0) {
            height = getResources().getDimensionPixelSize(resourceId);
        }
        return height;
    }
}
ColorPicker.java

package com.cfsuman.me.colorpickerexample;

import android.content.Context;
import android.graphics.Color;
import android.view.Gravity;
import android.view.View;
import android.view.ViewGroup;
import android.widget.ArrayAdapter;
import android.widget.GridView;
//import android.widget.RelativeLayout.LayoutParams;
//import android.view.ViewGroup.LayoutParams;
import android.widget.AbsListView.LayoutParams;
import android.widget.TextView;

import java.util.ArrayList;

public class ColorPicker {
    private Context mContext;
    // GridView column width and TextView width, height in pixels
    private static int columnWidth = 40;

    public ColorPicker(Context context){
        this.mContext = context;
    }

    public static View getColorPicker(Context mContext){
        // Initialize a new GridView widget
        GridView gv = new GridView(mContext);

        // Specify the GridView layout parameters
        gv.setLayoutParams(new LayoutParams(LayoutParams.MATCH_PARENT, LayoutParams.MATCH_PARENT));

        // Define column width and number of columns
        gv.setNumColumns(GridView.AUTO_FIT);
        gv.setColumnWidth(columnWidth); // Should be same as TextView width and height

        // Define addition settings of GridView for design purpose
        gv.setHorizontalSpacing(0);
        gv.setVerticalSpacing(0);
        gv.setStretchMode(GridView.STRETCH_COLUMN_WIDTH);
        gv.setBackgroundColor(Color.TRANSPARENT);
        gv.setPadding(5, 5, 5, 5);
        gv.setGravity(Gravity.CENTER);

        // Get the ArrayList of HSV colors
        final ArrayList colors = HSVColors();

        // Create an ArrayAdapter using colors list
        ArrayAdapter<Integer> ad = new ArrayAdapter<Integer>(mContext, android.R.layout.simple_list_item_1, colors) {
            @Override
            public View getView(int position, View convertView, ViewGroup parent) {
                // Cast the current view as a TextView
                TextView view = (TextView) super.getView(position, convertView, parent);

                // Get the current color from list
                int currentColor = (int) colors.get(position);

                // Set the background color of TextView as current color
                view.setBackgroundColor(currentColor);

                // Set empty text in TextView
                view.setText("");

                // Set the layout parameters for TextView widget
                LayoutParams lp = new LayoutParams(
                        LayoutParams.MATCH_PARENT, LayoutParams.MATCH_PARENT
                );
                view.setLayoutParams(lp);

                // Get the TextView LayoutParams
                LayoutParams params = (LayoutParams) view.getLayoutParams();

                // Set the TextView width and height in pixels
                // Should be same as GridView column width
                params.width = columnWidth; // pixels
                params.height = columnWidth; // pixels

                // Set the TextView layout parameters
                view.setLayoutParams(params);
                view.requestLayout();

                // Return the TextView as current view
                return view;
            }
        };

        // Specify the GridView data source
        gv.setAdapter(ad);

        // return the GridView
        return gv;
    }

    // Custom method to generate hsv colors list
    public static ArrayList HSVColors(){
        ArrayList<Integer> colors= new ArrayList<>();

        // Loop through hue channel, saturation and light full
        for(int h=0;h<=360;h+=20){
            colors.add(HSVColor(h, 1, 1));
        }

        // Loop through hue channel, different saturation and light full
        for(int h=0;h<=360;h+=20){
            colors.add(HSVColor(h, .25f, 1));
            colors.add(HSVColor(h, .5f, 1));
            colors.add(HSVColor(h, .75f, 1));
        }

        // Loop through hue channel, saturation full and light different
        for(int h=0;h<=360;h+=20){
            //colors.add(createColor(h, 1, .25f));
            colors.add(HSVColor(h, 1, .5f));
            colors.add(HSVColor(h, 1, .75f));
        }

        // Loop through the light channel, no hue no saturation
        // It will generate gray colors
        for(float b=0;b<=1;b+=.10f){
            colors.add(HSVColor(0, 0, b));
        }
        return colors;
    }

    // Create HSV color from values
    public static int HSVColor(float hue, float saturation, float black){
        /*
            Hue is the variation of color
            Hue range 0 to 360

            Saturation is the depth of color
            Range is 0.0 to 1.0 float value
            1.0 is 100% solid color

            Value/Black is the lightness of color
            Range is 0.0 to 1.0 float value
            1.0 is 100% bright less of a color that means black
        */
        int color = Color.HSVToColor(255,new float[]{hue,saturation,black});
        return color;
    }
}
