android kotlin - Fragment navigation drawer example

MainActivity.kt

package com.example.jetpack

import androidx.appcompat.app.AppCompatActivity
import android.os.Bundle
import android.view.View
import androidx.appcompat.app.ActionBarDrawerToggle
import androidx.core.view.GravityCompat
import androidx.fragment.app.Fragment
import kotlinx.android.synthetic.main.activity_main.*


class MainActivity : AppCompatActivity() {

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContentView(R.layout.activity_main)

        setSupportActionBar(toolbar)
        supportActionBar?.title = "DrawerLayout + Fragment"

        // Initially display the first fragment in main activity
        replaceFragment(FirstFragment())

        // Drawer toggle click listener
        val toggle:ActionBarDrawerToggle = object:ActionBarDrawerToggle(
            this,drawerLayout,toolbar,
            R.string.drawer_open,R.string.drawer_close
        ){
            override fun onDrawerOpened(drawerView: View) {
                super.onDrawerOpened(drawerView)
            }

            override fun onDrawerClosed(drawerView: View) {
                super.onDrawerClosed(drawerView)
            }
        }

        // Configure drawer layout
        toggle.isDrawerIndicatorEnabled = true
        toggle.syncState()
        drawerLayout.addDrawerListener(toggle)


        // Navigation view item click listener
        navigationView.setNavigationItemSelectedListener {
            drawerLayout.closeDrawer(GravityCompat.START)
            when(it.itemId){
                R.id.first->{
                    replaceFragment(FirstFragment())
                    true
                }
                R.id.second->{
                    replaceFragment(SecondFragment())
                    true
                }
                else->false
            }
        }
    }
}


// Extension function to replace fragment
fun AppCompatActivity.replaceFragment(fragment:Fragment){
    val fragmentManager = supportFragmentManager
    val transaction = fragmentManager.beginTransaction()
    transaction.replace(R.id.host,fragment)
    transaction.addToBackStack(null)
    transaction.commit()
}
activity_main.xml

<?xml version="1.0" encoding="utf-8"?>
<androidx.drawerlayout.widget.DrawerLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:id="@+id/drawerLayout">

    <androidx.constraintlayout.widget.ConstraintLayout
        android:layout_width="match_parent"
        android:layout_height="match_parent">
        <androidx.appcompat.widget.Toolbar
            android:id="@+id/toolbar"
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:background="#ff0"
            app:layout_constraintBottom_toTopOf="@+id/host"
            app:layout_constraintEnd_toEndOf="parent"
            app:layout_constraintStart_toStartOf="parent"
            app:layout_constraintTop_toTopOf="parent" />
        <androidx.constraintlayout.widget.ConstraintLayout
            android:id="@+id/host"
            android:layout_width="match_parent"
            android:layout_height="0dp"
            android:background="#FF5722"
            android:orientation="vertical"
            app:layout_constraintBottom_toBottomOf="parent"
            app:layout_constraintEnd_toEndOf="parent"
            app:layout_constraintStart_toStartOf="parent"
            app:layout_constraintTop_toBottomOf="@+id/toolbar">

        </androidx.constraintlayout.widget.ConstraintLayout>
    </androidx.constraintlayout.widget.ConstraintLayout>

    <!-- navigation menu -->
        <androidx.constraintlayout.widget.ConstraintLayout
            android:layout_width="wrap_content"
            android:layout_height="match_parent"
            android:layout_gravity="start"
            android:layout_marginTop="?attr/actionBarSize"
            >
            <com.google.android.material.navigation.NavigationView
                android:id="@+id/navigationView"
                android:layout_width="match_parent"
                android:layout_height="match_parent"
                app:menu="@menu/drawer_menu"
                android:background="#FFB29A"
                />
        </androidx.constraintlayout.widget.ConstraintLayout>

</androidx.drawerlayout.widget.DrawerLayout>
FirstFragment.kt

package com.example.jetpack

import android.os.Bundle
import androidx.fragment.app.Fragment
import android.view.LayoutInflater
import android.view.View
import android.view.ViewGroup


class FirstFragment : Fragment() {

    override fun onCreateView(
        inflater: LayoutInflater, container: ViewGroup?,
        savedInstanceState: Bundle?
    ): View? {
        // Inflate the layout for this fragment
        return inflater.inflate(R.layout.fragment_first, container, false)
    }
}
fragment_first.xml

<?xml version="1.0" encoding="utf-8"?>
<androidx.constraintlayout.widget.ConstraintLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context=".FirstFragment">
    <TextView
        android:id="@+id/textView"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_marginTop="32dp"
        android:text="First Fragment"
        android:textAppearance="@style/TextAppearance.AppCompat.Large"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toTopOf="parent"
        android:padding="25dp"
        />
</androidx.constraintlayout.widget.ConstraintLayout>
SecondFragment.kt

package com.example.jetpack

import android.os.Bundle
import androidx.fragment.app.Fragment
import android.view.LayoutInflater
import android.view.View
import android.view.ViewGroup

class SecondFragment : Fragment() {

    override fun onCreateView(
        inflater: LayoutInflater, container: ViewGroup?,
        savedInstanceState: Bundle?
    ): View? {
        // Inflate the layout for this fragment
        return inflater.inflate(R.layout.fragment_second, container, false)
    }
}
fragment_second.xml

<?xml version="1.0" encoding="utf-8"?>
<androidx.constraintlayout.widget.ConstraintLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context=".SecondFragment">
    <TextView
        android:id="@+id/textView"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_marginTop="32dp"
        android:text="Second Fragment"
        android:textAppearance="@style/TextAppearance.AppCompat.Large"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toTopOf="parent"
        android:padding="25dp"
        />
</androidx.constraintlayout.widget.ConstraintLayout>
res/menu/drawer_menu.xml

<?xml version="1.0" encoding="utf-8"?>
<menu xmlns:android="http://schemas.android.com/apk/res/android">
    <item
        android:id="@+id/first"
        android:title="First Fragment"
        android:icon="@drawable/ic_action_home"
        />
    <item
        android:id="@+id/second"
        android:title="Second Fragment"
        android:icon="@drawable/ic_action_info"
        />
</menu>
res/values/strings.xml

<resources>
    <string name="app_name">DrawerLayout With Fragment</string>

    <string name="drawer_open">open</string>
    <string name="drawer_close">close</string>
</resources>
res/values/styles.xml

<resources>

    <!-- Base application theme. -->
    <style name="AppTheme" parent="Theme.MaterialComponents.Light.NoActionBar">
        <!-- Customize your theme here. -->
        <item name="colorPrimary">@color/colorPrimary</item>
        <item name="colorPrimaryDark">@color/colorPrimaryDark</item>
        <item name="colorAccent">@color/colorAccent</item>
    </style>

</resources>
